- frame Aluminium Lite, AMF, Double Butted, Internal Cable Routing, Flat Mount Brake, SIC Mount, FM Kickstand Mount
- size Size Split: 27.5: XS, S // 29: M, L, XL, XXL
- Suspension fork SR Suntour XCT Disc, 100mm
- brake system Tektro HD-M275, Hydr, Disc Brake, PM/FM (160/160)
- rear derailleur Shimano Cues RD-U4000-GS, 9-Speed
- shifters Shimano Cues SL-U4010- Rapidfire-Plus
- bottom bracket Thun Paso-ML, 73mm BSA
- crankset Prowheel CC10Y-NW, 32T, 170mm
- cassette Shimano Cues CS-LG300, 11-46T
- chain KMC eGlide
- headset CUBE FPH868p, Tapered, Semi-Integrated
- Stem CUBE Performance Stem, 31.8mm
- handlebar CUBE Rise Trail Bar, 680mm
- grips ACID React
- rims CUBE EX25, 32H, Disc, Tubeless Ready
- front hub CUBE Alloy Light, QR, 6-Bolt
- rear hub CUBE Alloy Light, QR, 6-Bolt
- tyres CUBE MTB, 2.25
- saddle ACID Venec Lite
- seat post CUBE Performance Post, 27.2mm
- seat clamp CUBE Varioclose, 31.8mm
- pedals CUBE PP MTB
- colour fireorange´n´black
- weight 14,3 kg
- Structural Weight 140 kg
Geometry
|
XS |
S |
M |
L |
XL |
XXL |
| Seat tube |
340 |
370 |
420 |
470 |
515 |
560 |
| Top Tube Horizontal |
555 |
575 |
595 |
615 |
635 |
655 |
| Seat angle |
74° |
73.5° |
73.5° |
73.5° |
73.5° |
73.5° |
| Head tube angle |
68.5° |
68.5° |
68.5° |
68.5° |
68.5° |
68.5° |
| Chainstays |
427 |
427 |
450 |
450 |
450 |
450 |
| Head tube |
108 |
111 |
111 |
122 |
142 |
157 |
| Wheelbase |
1068 |
1082 |
1125 |
1146 |
1168 |
1190 |
| BB-Height to Hub |
52 |
52 |
65 |
65 |
65 |
65 |
| Protrusion height – 80mm |
707 |
720 |
759 |
792 |
824 |
858 |
| Reach |
384 |
398 |
409 |
426 |
441 |
457 |
| Stack |
595 |
598 |
627 |
637 |
656 |
670 |
Ergonomics
|
XS |
S |
M |
L |
XL |
XXL |
| Length seat post |
350 |
350 |
400 |
400 |
400 |
400 |
| Diameter seatpost |
27.2 |
27.2 |
27.2 |
27.2 |
27.2 |
27.2 |
| Angle stem |
6° |
6° |
6° |
6° |
6° |
6° |
| Crank length |
170 |
170 |
170 |
170 |
170 |
175 |
| Diameter tire maximum |
708 |
708 |
747 |
747 |
747 |
747 |
| Width tire maximum |
57 |
57 |
57 |
57 |
57 |
57 |
| Stem length |
50 |
50 |
60 |
60 |
70 |
70 |
| Handlebar width |
680 |
680 |
680 |
680 |
680 |
680 |
