- frame Aluminium 6061 T4/T6 Superlite, Road Comfort Geometry, Integrated Cable Routing, Flat Mount Disc, Integrated Seatpost Clamp, 12x142mm, AXH
- size 47cm, 50cm, 53cm, 56cm, 58cm, 60cm, 62cm
- Rigid fork Attain C:62®, Full Carbon, Integrated Cable Routing, Flat Mount, 12x100mm
- shift/ brake levers Shimano Claris ST-R2000
- brake system Tektro MD-C310, Flat Mount (160/160)
- rear derailleur Shimano Claris RD-R2000-GS, 8-Speed
- front derailleur Shimano Claris FD-R2000-BM, 31.8mm
- bottom bracket Shimano BB-RS500PB, Pressfit
- crankset Shimano Claris FC-R2000, 50x34T
- cassette Shimano CS-HG31, 11-34T
- chain KMC Z8.3
- headset ACROS, Top Integrated 1 1/2″ w/ Integrated Cable Routing, Bottom Integrated 1 1/4″
- Stem CUBE CIS Stem w/ Cable Routing
- handlebar CUBE Compact Race Bar
- handlebar tape ACID Bartape RC 3.0
- wheelset CUBE RA 2.3 Aero Disc
- tyres Conti Grand Prix, Kevlar, 30-622
- saddle ACID Nuance Lite
- seat post CUBE Performance Post, 27.2mm
- colour nightflight´n´grey
- weight 10,5 kg
- Structural Weight 115 kg
Geometry
| Slack/Moderate |
47 cm |
50 cm |
53 cm |
56 cm |
58 cm |
60 cm |
62 cm |
| Seat tube |
410 |
440 |
470 |
500 |
520 |
540 |
560 |
| Top Tube Horizontal |
510 |
517 |
537 |
560 |
575 |
590 |
595 |
| Seat angle |
74.6° |
74.6° |
74° |
73.5° |
73° |
72.5° |
72.5° |
| Head tube angle |
70.6° |
71.5° |
72° |
72.5° |
72.5° |
72.5° |
72.5° |
| Chainstays |
420 |
420 |
420 |
420 |
420 |
420 |
420 |
| Head tube |
120 |
130 |
152 |
182 |
202 |
222 |
242 |
| Wheelbase |
1000 |
1000 |
1008 |
1020 |
1020 |
1028 |
1036 |
| BB-Height to Hub |
74 |
74 |
74 |
74 |
74 |
74 |
74 |
| Protrusion height – 80mm |
709 |
732 |
759 |
790 |
808 |
828 |
848 |
| Reach |
375 |
378 |
384 |
391 |
394 |
396 |
393 |
| Stack |
525 |
538 |
561 |
591 |
610 |
630 |
648 |
Ergonomics
|
47 cm |
50 cm |
53 cm |
56 cm |
58 cm |
60 cm |
62 cm |
| Length seat post |
350 |
350 |
350 |
350 |
350 |
350 |
350 |
| Diameter seatpost |
27.2 |
27.2 |
27.2 |
27.2 |
27.2 |
27.2 |
27.2 |
| Crank length |
165 |
170 |
170 |
170 |
175 |
175 |
175 |
| Width tire maximum |
32 |
32 |
32 |
32 |
32 |
32 |
32 |
| Stem length |
70 |
90 |
90 |
100 |
100 |
100 |
110 |
| Handlebar width |
380 |
400 |
420 |
420 |
440 |
440 |
440 |
